Excavator Rock Saws For Quarrying, Earthmoving, Excavation, and Mining
High Performance Rock Saws
Long-lasting steel core blades have cutting teeth that can be easily interchanged on-site reducing downtime and maintenance.
Long-lasting blades can have teeth interchanged on-site with minimal downtime.
The Tungsten Carbide rock saw is the perfect rock-cutting attachment for:
- quarrying
- earthmoving
- excavation
- mining
This saw uses standard teeth, commonly used amongst road profilers.
No need for blade cooling or watering during cutting.
Tungsten Carbide Rock Saw Sizes & Specifications
| Model | Excavator Class (tons) | Blade Size (inch) (mm) | Cut Depth (inch) (mm) | Cut Width (inch) (mm) | Hydraulic Flow (gal/min) (L/min) | Shipping Dimensions (in) (cm) | Approx. Weight (lbs) (kg) |
|---|---|---|---|---|---|---|---|
| TCR5 | 18-30 | 681727.2 | 25635 | 2.564 | 30-35114-133 | 75 x 77 x 51191 x 196 x 130 | 2000900 |
| TCR8 | 25-50 | 1042641.6 | 421067 | 2.564 | 75-90 284-341 | 114 x 126 x 60290 x 320 x 152 | 60002700 |
| TCR10 | 30-50 | 1283251.2 | 541372 | 2.564 | 75-90284-341 | 136 x 102 x 136213 x 259 x 457 | 75003375 |
Tungsten Carbide Rock Saw Gallery
